Wiring Diagram: 1/4" or 1/8" Stereo PlugHere is a basic diagram on how to wire a 1/4″ or 1/8″ stereo plug. If you are going to use it for speaker connections, you do not want to use shielded cable.
|
|||||
|
I have the blessing (and sometimes the curse) of being relatively fearless in my endeavors. Couple that with an extreme and haunting curiosity – “I wonder what would happen if I did this?” – and you have the recipe for some pretty good messes. You have to break a few eggs to make an omelette, right? As a result, I have family and friends who call me for technical stuff, and I’ve found that there are a lot of people that look at the back of a computer, stereo, or even house wiring and go into brain freeze because there are so many connections. I guess some people just don’t like the smell of fried electronics. Hard to understand, but that’s O.K. There’s one thing I enjoy more than blowing up my stuff, and that’s blowing up someone elses! (Just kidding!) If you have a specific subject you want me to cover, or suggestions on how to improve the site, I’d be happy to hear from you – just e-mail me at mail@connecthowto.com or leave a comment on one of my posts. Radio noise!! The sound guy’s (gal’s) worst enemy! We had a church built about a year ago with a really nice sound system that was AMAZINGLY better than the old one. I was constantly fighting noise of some kind in the old church, so this new one made me almost giddy with excitement. I was like a kid in a candy store! Then it happened. We had a lightning strike! NOOOO!!!! Not everything was taken out, but just enough to limit our capabilities for a couple of weeks. We called in the professionals and they replaced everything that was apparently affected, but now we have a country-western radio station rearing it’s ugly head intermittently. Now don’t get me wrong – I have nothing against country-western music. I enjoy all types of music in their proper place. It’s just that I’m kind of a control freak and don’t appreciate uninvited music stations during the church service!! I think it may be coming in through the electrical service somehow, but the electricians that wired the new church are now out of business and the elders are hesitant about paying for someone to come in and troubleshoot the problem, so it looks like I’m going to have to get off my lazy butt and spend some time tearing into the church’s electrical systems to see if I can find a clue. Sigh…. honeymoon’s over. One positive note, though – I do enjoy a good challenge, and by golly, I’m not letting a radio ghost kick my butt!! More later… I FOUND IT!! Somehow one of the aux outs from my sound board got plugged into a line in. I’m going to blame one of the video guys because it was behind their computer ;>). I can see how it happened, though. First, let me explain how I have the video computer set up: There is a dual adapter plugged into the video computer speaker jack – one line goes to the sanctuary sound system and the other one is supposed to go to the local computer speakers. There is also an output from the sanctuary sound board that goes to the computer for recording the audio portion of the church service. At some point, the speakers got unplugged and the recording input line got plugged into the dual speaker output adapter. After I corrected it, the sound system output increased a lot, and the radio noise went away. (Please don’t make me explain where the radio noise came from or went to because I can’t) It took a couple of weeks to reset all my gains, but now I’m back in my happy place! Here is a diagram of some of the typical sound card input and output connections on a computer.  Computer Sound Card Connections There are normally at least 3 jacks (holes) and a rectangular connector in the sound card section of your computer. The audio output jack, the microphone input jack, the line input jack, and the game port. The 3 similar jacks accept a 1/8″ or 3.5mm (same size) plug. Of course, higher end cards may have more of these types of jacks for extra surround sound speakers, but I am only going to cover the basic type here. The rectangular connector is a 15 pin D-sub connector that’s called the game port. Audio Output Jack: DO NOT plug your electric guitar amplifier speaker OUTPUT into this jack, or you may have to go shoppin’. You can, however, plug a cord from this audio output jack into your guitar amplifier INPUT to greatly amplify the song playing on your computer. Doing that will also greatly amplify your parent’s/wife’s voice. ;>) Microphone Jack: Line Input Jack: Game Port:  Computer MIDI Game Port Pin Out For older computers that don’t have the MIDI capabilities, pin 12 would be connected to ground and pin 15 would be +5V out.
Stereo Adapter 1/4" - (2)RCA This adapter works well with connecting a headphone output with a line input or recording input. There are even some stereo speakers that have RCA type input jacks. As you can see, I have illustrated the right wire as being red and the left wire as being white. The wires aren’t typically those colors, but the casings usually are, and those colors are standard on all the stereo equipment that I’ve ever seen. Although this diagram illustrates how to wire a 1/4″ stereo plug, it’s the same diagram for a 1/8″ (3.5mm), only smaller. There are 2 diagrams below, the first one is a diagram of how to wire 3 switches to the same light. You use a combination of two 3-way switches with a 4-way switch in between. The second diagram shows how to wire 4 switches to the same light by adding another 4-way switch in series. You can hook up as many switches as you want by just adding 4-way switches, as long as you have a 3-way switch on each end. The white neutral wires all tie together to supply the light with a return (neutral) path, and the ground wires all tie together as well. If the switches have a ground screw, it would be good to connect the bare ground wires to them as a safety factor, but not absolutely essential for the circuit to work. Just remember that with connecting two 3-way switches, the hot wire goes to one of them and the switch leg goes to the other one, with two travelers in between.
 Wiring Diagram: 4-Way Switch (3 switches)  Wiring Diagram: 4-Way Switch (4 switches)
If the power feed (hot wire cable) and the switch leg (light wires) go into the same box, you can connect the wires like this: Since your light can pick up the neutral from the power feed in the same box, the white wires in your travelers can be used to transfer the switch leg to the last switch in your circuit. BUT – Be careful to mark the white wire you use for this somehow, like with a piece of black tape toward the end. Click here for a diagram that will give you a basic idea of what I’m talking about.
The great thing about computer connections is that they were designed to be “idiot proof” for the most part. Very few things can be plugged into the wrong place without force, and if it is plugged into the wrong place, usually no damage is done. All you have to do is match up the shapes of the cable ends to the connector on the back of the computer. Here’s a quick video that explains some of those connections: There are only 2 exceptions that I can think of where you can get things turned around with negative (but not drastic) results, and that’s the sound card connections and the PS/2 ports. The PS/2 ports are the 2 small round ones with several pins in them. Your mouse and keyboard plug into these. Typically they are color coded, but not always. There is usually a symbol next to them on the back of the case indicating which one goes where. If you get them switched, no harm done, they just won’t work right. Just turn the computer off, switch them, turn the computer back on, and they should work fine. I might add that the connectors need to be turned the right way before pushing them in. Never force them in. If they don’t seem to go in relatively easily, inspect the pins to see if any are bent. Here’s a diagram of the connections on the back of a Dell Dimension:
 Wire How To: Single Switch and Light This is a typical diagram of how to wire a light switch. There may or may not be a power out line that feeds something else in the circuit, or there may be more than one power out line, depending on what was handy for the electrician at the time. CAUTION: Ground Wire: Neutral Wire: Hot Wire: It’s always a good idea to twist the wires together with your pliers before screwing on the wire nut to ensure a good, solid connection. It will help to prevent intermittent problems.  Wire How To: Single Switch and Light (alternate) This wiring diagram is for when your power feed is in the light box instead of the switch box. You’ll notice the main difference being that you use the white wire in the cable going to the switch box as the switch leg and the black wire as the power feed. Some electricians will tie the white wire in with the power feed and use the black one as the switch leg, but either way, the switch doesn’t care which is which. Again, I cannot stress enough to be very careful with your connections here. If you accidentally tie the white wire from the switch into the other white wires in this configuration, there will be fireworks!
Here’s a wiring diagram of a light circuit with three lights hooked up to one switch and an outlet receptacle in the same circuit. You can hook up as many lights or receptacles together in this way as the circuit will handle.  Wire How To: Three Lights on a Single Switch and an Outlet Receptacle -  Wiring Diagram: 3-Way Switch This is a typical diagram of how to connect 2 switches to the same light. It’s especially handy for stairs, hallways, and big rooms. You will notice that the power feed goes into one switch box, while the switch leg (light wire) goes into the other. There is also a “traveler” line that connects the two together. Traveler:  Wiring Diagram: 3-Way Switch (alternate) This is an alternate way to wire 2 switches to the same light. Sometimes it’s more convenient to put both the power feed and the switch leg in the same switch box. One of the quickest and easiest ways to increase your computer’s speed and capabilities is to install more Random Access Memory (RAM). Here’s the How To steps: Find out how much RAM your computer has. Find out what type and how much RAM your motherboard will accept. If you know the manufacturer and model number of computer: If you have a generic computer or don’t know who made it: If all else fails: CAUTION: ALWAYS BE CAREFUL WHEN HANDLING COMPUTER COMPONENTS – STATIC ELECTRICITY CAN EASILY HARM OR DESTROY SOME OF THE CIRCUITS. ALWAYS REMOVE THE POWER AND GROUND YOURSELF (TOUCH THE CASE) BEFORE TOUCHING THE ELECTRONICS, AND USE ANTI-STATIC PACKAGING FOR STORAGE OR TRANSPORTATION WHENEVER POSSIBLE. Installation: Disclaimer: Eveything on this website is for my entertainment only – If you screw up and break something or hurt yourself, you’re on your own. |
|||||
|
